UA78M05IDCYR Lipo Battery Charger IC Circuit , Battery Controller IC For Portable Devices

Brand Name : TI

Model Number : UA78M05IDCYR

MOQ : Contact us

Price : Contact us

Payment Terms : Paypal, Western Union, TT

Supply Ability : 50000 Pieces per Day

Delivery Time : The goods will be shipped within 3 days once received fund

Packaging Details : SOT223

Description : Linear Voltage Regulator IC Positive Fixed 1 Output 500mA SOT-223-4

Input Voltage - Min : 7 V

Input Voltage - Max : 25 V

Minimum Operating Temperature : - 40 C

Maximum Operating Temperature : + 125 C

Condition : Original 100%,New and Original

Stock status : In Stock

Contact Now

UA78M05IDCYR Power Path Management IC Linear Voltage Regulators 5V 500mA Fixed Pos Voltage Regulator

1 Features

3-Terminal Regulators
Output Current up to 500 mA
No External Components
Internal Thermal-Overload Protection
High Power-Dissipation Capability
Internal Short-Circuit Current Limiting
Output Transistor Safe-Area Compensation

2 Applications

On-Card Regulation
Portable Devices
Computing & Servers
Telecommunications

3 Description

This series of fixed-voltage integrated-circuit voltage regulators is designed for a wide range of applications. The applications include on-card regulation for elimination of noise and distribution problems associated with single-point regulation. Each of these regulators can deliver up to 500 mA of output current. The internal current-limiting and thermal-shutdown features of these regulators essentially make them immune to overload. In addition to use as fixed-voltage regulators, these devices can be used with external components to obtain adjustable output voltages and currents and also as the power-pass element in precision regulators.

Device Information

PART NUMBER	PACKAGE	BODY SIZE (NOM)
UA78Mxx	SOT-223 (3)	6.50 mm x 3.50 mm
	TO-220 (3)	10.16 mm x 8.82 mm
	TO-252 (3)	6.60 mm x 6.10 mm

Product Tags:

microchip battery management

power management integrated circuit

Wholesale UA78M05IDCYR Lipo Battery Charger IC Circuit , Battery Controller IC For Portable Devices from china suppliers

UA78M05IDCYR Lipo Battery Charger IC Circuit , Battery Controller IC For Portable Devices Images
