PMEG6010ER 1A Low VF MEGA Schottky Barrier Rectifier SOD123

Name: PMEG6010ER 1A Low VF MEGA Schottky Barrier Rectifier SOD123
Brand: Nexperia
Price: 1 USD

Brand Name : Nexperia

Model Number : PMEG6010ER

Certification : CE/ RoHS

Place of Origin : USA

MOQ : 10pcs

Price : To be negotiated

Payment Terms : T/T, Western Union ,paypal

Supply Ability : 10,000PCS

Delivery Time : in stock 2-3days

Packaging Details : Reel

Description : Diode 60 V 1A Surface Mount SOD-123W

PN : PMEG6010ER

BRANDS : Nexperia

ORIGINAL : USA

TYPE : low VF MEGA Schottky barrier rectifier

CURRENT : 1 A

PACKAGE : SOD123

Contact Now

PMEG6010ER 1 A low VF MEGA Schottky barrier rectifier

1.1 General description

Planar Maximum Efficiency General Application (MEGA) Schottky barrier rectifier with an

integrated guard ring for stress protection, encapsulated in a SOD123W small and flat

lead Surface-Mounted Device (SMD) plastic package.

1.2 Features and benefits

Average forward current: IF(AV) ≤ 1 A

Reverse voltage: VR ≤ 60 V

Low forward voltage

High power capability due to clip-bond technology

AEC-Q101 qualified

Small and flat lead SMD plastic package

1.3 Applications

Low voltage rectification

High efficiency DC-to-DC conversion

Switch Mode Power Supply (SMPS)

Reverse polarity protection

Low power consumption applications
