2N7002PW Surface Mount NPN PNP Transistors N Channel 60V 310mA ( Ta ) 260mW

Model Number : 2N7002PW

Place of Origin : Malaysia

MOQ : 3000 PCS

Price : Negotiation

Supply Ability : T/T, Western Union ， ESCROW

Delivery Time : 30000PCS

Packaging Details : 3000PCS/REEL

Description : N-Channel 60 V 315mA (Ta) 260mW (Ta) Surface Mount SOT-323

Categories : Transistors - FETs, MOSFETs - Single

Drain to Source Voltage : 60V

Current - Continuous Drain (Id) @ 25°C : 310mA (Ta)

Drive Voltage : 10V

Rds On (Max) @ Id, Vgs : 1.6 Ohm @ 500mA, 10V

Vgs(th) (Max) @ Id : 2.4V @ 250µA

Gate Charge (Qg) (Max) @ Vgs : 0.8nC @ 4.5V

Input Capacitance (Ciss) (Max) @ Vds : 50pF @ 10V

Contact Now

2N7002PW NPN PNP Transistors N-Channel 60V 310mA (Ta) 260mW (Ta) Surface Mount SC-70

Description
This MOSFET has been designed to minimize the on-state resistance (RDS(ON)) and yet maintain superior switching performance, making it ideal for high efficiency power management applications.
Applications
 Motor Control 
Power Management Functions

Features 
Low On-Resistance 
Low Gate Threshold Voltage 
Low Input Capacitance 
Fast Switching Speed 
Small Surface Mount Package 
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2) 
Halogen and Antimony Free. “Green” Device (Notes 3 & 4) 
Qualified to AEC-Q101 standards for High Reliability
Mechanical Data 
Case: SOT23 
Case Material: Molded Plastic, “Green” Molding Compound. UL Flammability Classification Rating 94V-0  Moisture Sensitivity: Level 1 per J-STD-020 
Terminals: Matte Tin Finish annealed over Alloy 42 leadframe (Lead Free Plating). Solderable per MIL-STD-202, Method 208 
Terminal Connections: See Diagram 
Weight: 0.008 grams (approximate)

Product Attributes	Select All
Categories	Discrete Semiconductor Products
	Transistors - FETs, MOSFETs - Single
Manufacturer	Nexperia USA Inc.
Series	-
Packaging	Tape & Reel (TR)
Part Status	Active
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25°C	310mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	1.6 Ohm @ 500mA, 10V
Vgs(th) (Max) @ Id	2.4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	0.8nC @ 4.5V
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	50pF @ 10V
FET Feature	-
Power Dissipation (Max)	260mW (Ta)
Operating Temperature	-55°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	SC-70
Package / Case	SC-70, SOT-323
